Specifications
qEngine
Item Specification
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 2,488 ml (2,488 cc, 151.8 cu in)
Compression ratio 9.7
qElectrical System
Item Classification
Battery 12V-48AH/5HR, 12V-52AH/5HR
Spark-plug number LFG1 18110
*1
, L3Y2 18 110
Spark-plug gap 1.25―1.35 mm (0.049―0.053 in)
*1 ex factory
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate
coating on the iridium alloy and platinum tips could be damaged.
qLubricant Quality
Lubricant Classification
Engine oil Refer to Recommended Oil on page 8-18.
Manual transaxle oil
API Service GL-4
SAE 75W-80
Automatic transaxle fluid Mazda Genuine ATF M-V
Power steering fluid
Mazda Genuine ATF M-III , M-V, or equivalent
(e.g. Dexron® II)
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
10-4
