4. Turn the socket and bulb assembly
counterclockwise and remove it.
5. Disconnect the bulb from the socket.
6. Install the new side turn signal unit in
the reverse order of removal.
Front turn signal lights/Parking lights
1. If you are changing the right headlight
bulb, start the engine, turn the steering
wheel all the way to the right, and turn
off engine. If you are changing the left
headlight bulb, turn the steering wheel
to the left.
2. Make sure the ignition is switched off,
and the headlight switch is off.
3. Turn the bolt, the screws and the center
section of the plastic retainers
counterclockwise and remove them,
then partially peel back the mudguard.
Removal
Installation
4. Turn the socket and bulb assembly
counterclockwise and remove it.
5. Disconnect the bulb from the socket.
Maintenance and Care
Owner Maintenance
8-43
