4 – 23
When Driving
Instrument Cluster and Display
The active driving display indicates the following information:
y
Mazda Radar Cruise Control (MRCC) Operation Conditions and Warnings

Refer to Mazda Radar Cruise Control (MRCC) on page 4-93 .
y
Lane Departure Warning System (LDWS) Operation Conditions and Warnings

Refer to Lane Departure Warning System (LDWS) on page 4-74 .
y
Smart City Brake Support (SCBS) Operation Conditions

Refer to Smart City Brake Support (SCBS) on page 4-104 .
y
Smart Brake Support (SBS) Operation Conditions and Warnings

Refer to Smart Brake Support (SBS) on page 4-109 .
y
Distance Recognition Support System (DRSS) Operation Conditions and Warnings

Refer to Distance Recognition Support System (DRSS) on page 4-87 .
y
Vehicle Speed Setting Using Cruise Control

Refer to Cruise Control on page 4-122 .
y
Turn-by-Turn (TBT) (Direction and Distance) and Lane Guidance
y
Vehicle Speed
Each setting/adjustment for the active driving display can be performed on the center
display (Type B audio).
1. Select the
icon on the home screen and display the Settings screen.
2. Select the AD-Disp tab.
3. Select the desired item and perform the setting/adjustment.

y

Height : Active driving display position

y

Brightness Control : Method for adjusting screen brightness (Automatically/Manually)

y

Calibration : Brightness initialization setting (when selecting automatic adjustment)

y

Brightness : Brightness adjustment (when selecting manual adjustment)

y

Navigation : On/Off

y

Active Driving Display : On/Off

y

Reset
