6 – 36
Maintenance and Care
Owner Maintenance
1. Remove the cover.
2. Remove the stopper and raise the wiper
arm.
Stopper
3. Firmly rotate the wiper blade to the
right until it unlocks, then remove the
blade.
CAUTION
To prevent damage to the rear window,
do not let the wiper arm fall on it.
4. Pull down the blade rubber and slide it
out of the blade holder.
5. Remove the metal stiffeners from the
blade rubber and install them in the
new blade.
CAUTION
Do not bend or discard the sti eners.
You need to use them again.
6. Carefully insert the new blade rubber.
Then install the blade assembly in the
reverse order of removal.
