Mazda 2016 CX3 - Page 444

6 – 52
Maintenance and Care
Owner Maintenance
Replacing Interior Light Bulbs
Overhead lights (Front)/Map lights,
Overhead lights (Rear)
1. Wrap a small fl athead screwdriver
with a soft cloth to prevent damage to
the lens, and then remove the lens by
carefully prying on the edge of the lens
with the fl athead screwdriver.
2. Disconnect the bulb by pulling it out.
Overhead lights (Front)/Map lights
Overhead lights (Rear)
Edge
3. Install the new bulb in the reverse order
of the removal procedure.
Luggage compartment light
1. Wrap a small fl athead screwdriver
with a soft cloth to prevent damage to
the lens and remove the lens unit by
carefully prying on the edge of the lens
unit with the fl athead screwdriver.
2. Disconnect the bulb by pulling it out.
3. Install the new bulb in the reverse order
of the removal procedure.
