7 – 15
If Trouble Arises
Flat Tire
6. Remove the luggage compartment
cover (if equipped).
Refer to Luggage Compartment on
page 3-21 .
Strap
Pin
Pin
7. Remove the belt for securing the fl at
tire.
8. Pull the luggage board outward and
place it on top of the luggage mat.
NOTE
The luggage board rests at an angle on
vehicles with a sub-woofer.
Luggage board
Luggage mat
Luggage mat
Luggage board
9. Remove the center cap by tapping it
with the lug wrench.
