Black plate (286,1)
3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverse order
of removal.
Overhead light (Rear)
1. Wrap a small flathead screwdriver with
a soft cloth to prevent damage to the
lens and remove the lens by carefully
prying on the edge of the lens with the
flathead screwdriver.
2. Disconnect the bulb by pulling it out.
3. Install the new bulb in the reverse order
of removal.
Luggage compartment light
1. Wrap a flat head screwdriver with a soft
cloth to prevent damage to the trim and
gently insert it in the luggage
compartment light as shown in the
figure, and then remove the luggage
compartment light unit.
2. Disconnect the bulb by pulling it out.
3. Install the new bulb in the reverse order
of removal.
8-40
Maintenance and Care
Owner Maintenance
Mazda5_8U38-EA-05D_Edition1 Page286
Monday, March 28 2005 2:32 PM
Form No.8U38-EA-05D
