4. Disconnect the bulb from the socket.
Reverse lights
Rear turn signal lights
Brake lights/Taillights
5. Install the new bulb in the reverse order
of removal.
License plate lights
1. Remove the liftgate cover.
2. Pull the socket and bulb assembly and
remove it.
3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverse order
of removal.
qReplacing Interior Light Bulbs
Overhead light/Map lights (Front)
1. Wrap a flat head screwdriver with a soft
cloth to prevent damage to the trim and
gently insert it in the overhead light as
shown in the figure, and then remove
the overhead light unit.
2. Turn the socket and bulb assembly
counterclockwise and remove it.
Maintenance and Care
Owner Maintenance
8-39
