Black plate (367,1)
3 Pull out the battery cover being
careful not to allow it to contact
the cowl grille.
Battery cover
Cowl grille
Installing battery cover
1 Being careful not to contact the
cowl grille, insert the tabs on the
one end of the battery cover into
the holes of th e battery tray and
engage the tabs.
Cowl grille
Tabs
Holes
2 Attach the clips on both sides of
the battery cover.
Clip
qBattery Maintenance
To get the best service from a battery:
l
Keep it securely mounted.
l
Keep the top clean and dry.
l
Keep terminals and connections clean,
tight, and coated with petroleum jelly
or terminal grease.
l
Rinse off spilled electrolyte
immediately with a solution of water
and baking soda.
l
If the vehicle will not be used for an
extended time, disconnect the battery
cables.
Maintenance and Care
Owner Maintenance
8-35
