3. Install the new bulb in the reverse order
of remova l.
Fuses
Your vehicle's electrical system is
protected by fuses.
If any lights, accessories, or controls don't
work, inspect the appropriate circuit
protector. If a fuse has blown, the inside
element will be melted.
If the same fuse blows again, av oid using
that system and consult an Authorized
Mazda Dealer as soon as possible.
qFuse Replacement
Replacing the fuses on the passenger's
side
If the electrical system doesn't work, first
inspect fuses on the passenger's side.
1. Turn off the ignition switch and other
switches.
2. Remove the cover.
CAUTION
Pulling the cover off sideways may
break the retaining tabs off.
Maintenance and Care
Owner Maintenance
8-45
