Anchor bracket location (Second-row
seats)
Marking
Tether strap position (Second-row
seats)
Tether strap
Anchor
bracket
Anchor bracket location (Third-row
seat)
Anchor
bracket
Marking
Tether strap position (Th ird-row seat)
Tether strap
WARNING
Use the tether and tether anchor only
for a child-restraint system:
Using the tether or tether anchor to
secure anything but a child-restraint
system is dangerous. This could
weaken or damage the tether or tether
anchor and result in injury.
Always route the tether strap between
the head restraint and the seatback
(Second-row seats):
Routing the tether strap on top of the
head restraint is dangerous. In a
collision the tether strap could slide off
the head restraint and loosen the
child-restraint system. The child -
restraint system could move which
may result in death or injury to the
child.
2-30
Essential Safety Equipment
Child Restraint
