Meters and Gauges
(Black-out meter)
When the ignition switch is in the ON position, the dashboard gauges illuminate.
Speedometer ............... ....................................................................................... page 5-25
Odometer, Trip Meter and Trip Meter Select or .................................................. page 5-25
Tachometer ........................................................................................................ page 5-26
Engine Coolant Temperature Gauge .................................................................. page 5-26
Fuel Gauge ........................................................................................................ page 5-27
5-24
Driving Your Mazda
Instrument Cluster and Indicators
