Signal Warning/Indicator Lights Page
AWD Warning Light 4-21
Automatic Transaxle Warning Light 4-21
Power Steering Malfunction Indicator Light 4-22
Air Bag/Front Seat Belt Pretensioner System Warning Light 4-22
Low Fuel Warning Light 4-18
Check Fuel Cap Warning Light 4-23
Seat Belt Warning Light 4-23
Door-Ajar Warning Light 4-24
Low Washer Fluid Level Warning Light 4-25
Tire Pressure Monitoring System Warning Light 4-25
KEY Warning Light (Red)/Indicator Light (Green) 4-26
Traction Control System (TCS)/Dynamic Stability Control (DSC) Indicator
Light
4-27
Traction Control System (TCS) OFF Indicator Light 4-28
Adaptive Front Lighting System (AFS) OFF Indicator Light 4-28
Low Engine Coolant Temperature Indicator Light (Blue) 4-28
Shift Position Indicator Light 4-28
