Black plate (57,1)
Supplemental Restraint System Components
Driver/Front passenger inflators and air bags
Roll-over sensor
í
, crash sensors, and diagnostic module (SAS unit)
Front seat belt pretensioners (page 2-17)
Front air bag sensors
Side crash sensors
Air bag/front seat belt pretensioner system warning light (page 4-15)
Side and curtain inflators and air bags
Front passenger air bag deactivation indicator light (page 2-53)
Front passenger seat weight sensors (page 2-53)
Front passenger seat weight sensor control module
Driver and front passenger seat belt buckle switches (page 2-58)
Driver seat slide position sensor (page 2-53)
NOTE
- are equipped only on models with the driver and front passenger occupant classification
system.
Essential Safety Equipment
SRS Air Bags
2-45
í
Some models.
CX-5_8CA5-EA-11L_Edition3 Page57
Friday, June 22 2012 3:44 PM
Form No.8CA5-EA-11L
