Black plate (406,1)
Rear
CAUTION
Do not use excessive force as it may
damage the cap or scratch the
painted bumper surface.
NOTE
Remove the cap completely and store it so as
not to lose it.
3. Securely install the tiedown eyelet
using the lug wrench.
Front
Tiedown eyelet
(Long type)
Lug wrench
Rear
Tiedown eyelet
(Short type)
Lug wrench
4. Hook the tying rope to the tiedown
eyelet.
Front
Tiedown eyelet
(Long type)
Rear
Tiedown eyelet
(Short type)
7-22
If Trouble Arises
Emergency Towing
