Roll-over (Without Driver and Front Passenger Occupant Classification System)
(With Driver and Front Passenger Occupant Classification System)
Limitations to roll-over detection:
The foll owing illust ration is an example of an accident that may not be detected as a roll-
over accident. Therefore, the front seat belt pretensioners and curtain air bags may not
deploy.
Pitch end over end
2-52
Essential Safety Equipment
SRS Air Bags
