6
INSPECT DSC HU/CM GROUND FOR POOR GROUND OR
OPEN CIRCUIT
Switch the ignition to off.
Measure the resistance between the DSC
HU/CM terminal AL (vehicle harness-side)
and body ground.
Is the resistance within 0—1 ohm?
Yes Go to the next step.
No If there is open circuit:
Repair or replace
the wiring harness,
then go to the
next step.
If resistance is not within
specification:
Repair or replace
the poor ground
part, then go to
the next step.
7
VERIFY THAT THE SAME DTC IS NOT PRESENT
Reconnect all disconnected connectors.
Clear the DTCs from the memory.
(See
ON-BOARD DIAGNOSIS [DYNAMIC
STABILITY CONTROL (DSC)]
.)
Start the engine and drive the vehicle at 20
km/h {12 mph} or more.
Are the same DTCs present?
Yes Repeat the inspection from Step 1.
No Go to the next step.
8
VERIFY THAT NO OTHER DTCS ARE PRESENT
Are any other DTCs output?
Yes Go to the applicable DTC
inspection.
(See
ON-BOARD DIAGNOSIS
[DYNAMIC STABILITY CONTROL
(DSC)]
.)
No DTC troubleshooting completed.
