DTC U3003:08/U3003:16/U3003:17 [DYNAMIC STABILITY CONTROL (DSC)]
http://am.mazdaserviceinfo.com/emazda/dealersystem/service/esi/en_us/SM/2013/CX5/mv/books/mvw04/html/id0402b2902000.html[1/7/13 9:30:55 AM]
2
Is battery specific gravity as specified?
Yes Go to the next step.
No Replace the battery, then go to
Step 7.
(See
BATTERY
REMOVAL/INSTALLATION
[SKYACTIV-G 2.0]
.)
3
INSPECT CHARGING SYSTEM
Are the generator and the drive belt tensions
normal?
Yes Go to the next step.
No Replace the generator and/or drive
belt if necessary.
(See
GENERATOR
REMOVAL/INSTALLATION
[SKYACTIV-G 2.0]
.)
(See
DRIVE BELT
REMOVAL/INSTALLATION
[SKYACTIV-G 2.0]
.)
Go to Step 7.
4
INSPECT FUSE CONDITION
Inspect the following fuses.
SRS1 7.5A
ABS/DSC S 30A
ABS/DSC M 50A
Is the fuse normal?
Yes Go to the next step.
No Replace the fuse, then go to Step
7.
5
INSPECT DSC HU/CM POWER SUPPLY FOR OPEN
CIRCUIT
Disconnect the DSC HU/CM connectors.
Switch the ignition ON (engine off).
Measure the voltage between following
connector terminals of the DSC HU/CM
(vehicle harness-side) and body ground:
DSC HU/CM: A—Body
ground
DSC HU/CM: B—Body
ground
DSC HU/CM: Q—Body
ground
Is the voltage 10 V or more?
Yes Go to the next step.
No Repair or replace the wiring
harness, then go to Step 7.
To Next Page
