DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
13
AUDIO
DCDC REG
30 A Audio system
14 FAN GE 30 A
Cooling fan
*
15 ENG.MAIN 40 A Engine control system
16 ABS/DSC M 50 A ABS, Dynamic stability control system
17 FAN DE 40 A
Cooling fan
*
18 WIPER 20 A Front window wiper and washer
19 HEATER 40 A Air conditioner
20 ADD FAN GE 30 A
Cooling fan
*
21 ENGINE.IG1 7.5 A Engine control system
22 C/U IG1 15 A For protection of various circuits
23 AUDIO2 7.5 A Audio system
24 METER2 7.5 A ―
25 ENGINE3 15 A Engine control system
26 ENGINE2 15 A Engine control system
27 ENGINE1 15 A
Engine control system
*
28 AT 15 A Transaxle control system, Ignition switch
29 H/CLEAN 20 A ―
30 A/C 7.5 A Air conditioner
31 AT PUMP 15 A ―
32 HORN 15 A Horn
33 R.WIPER 15 A Rear window wiper
34 H/L HI 20 A Headlight high beam
35 ST.HEATER 15 A
Heated steering wheel
*
36 FOG 15 A
Fog lights
*
37 ENG.+B 7.5 A Engine control system
38 H/L LOW L 15 A Headlight low beam (LH)
39 ENGINE4 15 A
Engine control system
*
40 INTERIOR1 15 A For protection of various circuits
41 METER1 10 A Instrument cluster
42 SRS1 7.5 A Air bag
43 AUDIO1 15 A Audio system
44 BOSE 25 A
Bose Sound System-equipped model
*
45 ABS/DSC S 30 A ABS, Dynamic stability control system
46 FUEL PUMP 15 A
Fuel system
*
