DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
6 D.LOCK 25 A Power door locks
7 SEAT WARM 20 A
Seat warmer
*
8 SUNROOF 10 A
Moonroof
*
9 F.OUTLET 15 A Accessory sockets
10 MIRROR 7.5 A Power control mirror
11 R.OUTLET1 15 A ―
12 SCR3 15 A
Engine control system
*
13 SCR4 15 A
Engine control system
*
14 R.OUTLET2 15 A Accessory sockets
15 USB 7.5 A
USB power outlet
*
16 PLG 20 A
Power liftgate
*
17 M.DEF 7.5 A
Mirror defogger
*
18 R.SEAT W 20 A
Rear seat warmer
*
19 INTERIOR2 15 A For protection of various circuit
20 AT IND 7.5 A AT shift indicator
21 P.SEAT P 30 A
Power seat
*
Maintenance and Care
Owner Maintenance
*Some models.
6-59
