Obstruction Detection Indication
The position of a sensor which has detected an obstruction is indicated. The gauge
illuminates in different areas depending on the distance to an obstruction detected by the
sensor.
As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the
vehicle illuminates.
Front left corner
sensor gauge
Front right corner
sensor gauge
Rear right corner
sensor gauge
Rear left corner
sensor gauge
Front sensor gauge
Rear sensor gauge
Some models.
NOTE
The detection indicator can switch between display and non-display.
Refer to Personalization Features on page 9-11.
When Driving
Parking Sensor System
4-176
