Weights
U.S.A. and Canada
Item
Weight
2WD AWD
GVWR (Gross Vehicle Weight Rating) 2,568 kg (5,661 lbs) 2,638 kg (5,816 lbs)
GAWR (Gross Axle Weight Rating)
Front 1,217 kg (2,683 lbs) 1,241 kg (2,736 lbs)
Rear 1,386 kg (3,056 lbs) 1,433 kg (3,159 lbs)
Mexico
Item
Weight
2WD AWD
GVW (Gross Vehicle Weight)
Total 2,495 kg (5,500 lbs) 2,565 kg (5,655 lbs)
Front 1,180 kg (2,601 lbs) 1,200 kg (2,646 lbs)
Rear 1,315 kg (2,899 lbs) 1,365 kg (3,009 lbs)
GAW (Permissible axle load)
Front 1,200 kg (2,646 lbs) 1,225 kg (2,701 lbs)
Rear 1,370 kg (3,020 lbs) 1,420 kg (3,131 lbs)
▼
Air Conditioner
The type of refrigerant used is indicated on a label attached to the inside of the engine com-
partment. Check the label before recharging the refrigerant. Refer to Climate Control Sys-
tem on page 5-4.
Item Classification
Refrigerant Type HFC134a (R-134a)
Specifications
Specifications
9-6
