Front Air Conditioner
Climate control system information is displayed on the display.
Passenger temperature
control dial
Rear window defogger switch
Mode selector switch
Airflow display
Fan control switch
AUTO switch
OFF switch
Temperature setting display (Passenger’s side)
Windshield defroster switch
Air intake selector (recirculated air position)
Temperature setting display (driver’s side)
Driver temperature control dial A/C mode display
Mode
selector
display
A/C switch
DUAL switch
Interior Features
Climate Control System
5-7
