Rear turn signal lights
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Remove the cover.
3. Turn the screws counterclockwise and
remove them.
4. Pull the unit rearward to remove it.
5. Disconnect the wiring harness by
releasing the clamp.
6. Turn the socket and bulb assembly
counterclockwise and remove it.
Maintenance and Care
Owner Maintenance
6-48
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38
