Mazda CX­3 2016 - Selector Cable Removal;Installation; Disconnect Battery Cable; Remove Selector Lever Knob; Remove Selector Cable (Lever Side)

1Connector
2Screw
3Indicator
SelectorCableRemoval/Installation
1.Disconnectthenegativebatterycable.(SeeNEGATIVEBATTERYCABLE
DISCONNECTION/CONNECTION.)
2.Removetheselectorleverknob.(SeeSelectorLeverRemoval/Installation.)
3.Performthefollowingproceduretoremovetheselectorcable(selectorleverside).
a.Removethecenterconsoletray.(SeeCENTERCONSOLETRAY
REMOVAL/INSTALLATION.)
b.Removetheshiftbezel.(SeeSHIFTBEZELREMOVAL/INSTALLATION.)
c.Removetheupperpanel.(SeeUPPERPANELREMOVAL/INSTALLATION.)
d.Removetheshiftpanel.(SeeSHIFTPANELREMOVAL/INSTALLATION.)
e.Removetheconsolesidepanel.(SeeCONSOLESIDEPANEL
REMOVAL/INSTALLATION.)
f.Removethefrontconsolebox.(SeeFRONTCONSOLEBOX
REMOVAL/INSTALLATION.)
g.RemovetheCDplayer.(SeeCDPLAYERREMOVAL.)(SeeCDPLAYER
INSTALLATION.)
h.Removethefrontconsole.(SeeFRONTCONSOLEREMOVAL/INSTALLATION.)
i.Removethesidewall.(SeeSIDEWALLREMOVAL/INSTALLATION.)
j.Removetherearconsole.(SeeREARCONSOLEREMOVAL/INSTALLATION.)
