When Driving
Parking Sensor System
The system is cancelled under the following conditions:
The parking sensor switch is pressed while the parking sensor is in operation.
The vehicle speed is 10 km/h (6 mph) or more.
Without front sensor and front corner sensor
When the ignition is switched ON and the shift lever is shifted to the reverse (R), the beep
sound activates and the system is enabled for use.
The sensors detect obstructions under the following conditions:
Sensor Condition
Rear Sensor The shift lever is in reverse (R).
Rear Corner Sensor
The shift lever is in reverse (R), and the vehicle speed is about 10 km/h (6 mph) or
less.
Obstruction Detection Indication (with Front Sensor and Front Corner
Sensor)
The position of a sensor which has detected an obstruction is indicated. The gauge
illuminates in different areas depending on the distance to an obstruction detected by the
sensor.
As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the
vehicle illuminates.
Without rear view monitor With rear view monitor
Right corner
sensor gauge
Right corner
sensor gauge
Left corner
sensor gauge
Left corner
sensor gauge
Front
sensor
gauge
Right corner
sensor gauge
Left corner
sensor gauge
Front sensor gauge
Rear sensor gauge
Right corner
sensor gauge
Left corner
sensor gauge
Rear
sensor
gauge
