If Trouble Arises
Flat Tyre
Removing a Flat Tyre
1. If your vehicle is equipped with a
wheel cover, pry off the wheel cover
with the bevelled end of the jack lever.
NOTE
Force the end of the jack lever fi rmly
between wheel and cover, or removal
will be diffi cult.
2. Loosen the wheel nuts by turning them
anticlockwise one turn each, but do not
remove any wheel nuts until the tyre
has been raised off the ground.
3. Place the jack on the ground.
4. Turn the jack screw in the direction
shown in the fi gure and adjust the jack
head so that it is close to the jack-up
position.
Jack head
5. Place the jack under the jack-up
position closest to the tyre being
changed with the jack head squarely
under the jack-up point.
Jacking position
To Next Page
