6. Left front corner ultrasonic sensor
gauge
*
With 360°view monitor
1. Front ultrasonic sensor gauge
2. Right front corner ultrasonic sensor
gauge
3. Right rear corner ultrasonic sensor
gauge/Right rear side ultrasonic sensor
gauge
*
4. Rear ultrasonic sensor gauge
5. Left rear corner ultrasonic sensor
gauge/Left rear side ultrasonic sensor
gauge
*
6. Left front corner ultrasonic sensor
gauge
NOTE
The detection indicator can switch
between display and non-display.
Refer to the Settings section in the MZD
Connect Owner's Manual.
System problem notification
The indication displays if the system has a
malfunction.
Without 360°view monitor
With 360°view monitor
Check the reason for the indication
displaying on the centre display or
multi-information display.
Refer to If a Warning Light Turns On or
Flashes on page 7-23.
When Driving
Parking Sensor System
*Some models.
4-241
