Seat Belt Warning
Systems
▼
Seat Belt Warning Systems
If it detects that the occupant seat belt
is unfastened, the warning light or
beep alerts the occupant.
Refer to Seat Belt Warning Indication/
Warning Light (Front seat) on page
7-42.
Refer to Seat Belt Warning Light (Rear
seat) (Red) on page 7-42.
Refer to Seat Belt Warning Beep on
page 7-49.
Seat belt indicator light (rear seat)
(green)
The light turns on when the rear seat
belt is fastened while the power switch
is switched ON, and it turns o after a
certain period.
Seat Belt Pretensioner
and Load Limiting
Systems
▼
Seat Belt Pretensioner and Load
Limiting Systems
For optimum protection, the front seat
belts and rear outboard seat belts
*
are
equipped with pretensioner and load
limiting systems. For both these
systems to work properly you must
wear the seat belt properly.
Pretensioners:
When a collision is detected, the
pretensioners deploy simultaneously
with the air bags.
The pretensioners deploy
simultaneously with the air bags when
a roll-over is also detected.
For deployment details, refer to the
SRS Air Bag Deployment Criteria (page
2-62).
The seat belt retractors remove slack
quickly as the air bags are expanding.
Any time the air bags and seat belt
pretensioners have fired they must be
replaced.
A system malfunction or operation
conditions are indicated by a warning.
Refer to Air Bag/Seat Belt Pretensioner
System Warning Indication/Warning
Light on page 7-39.
In addition, the pretensioner system
for the front passenger, like the front
and side passenger air bag, is designed
to only deploy when the front
passenger air bag deactivation switch
is turned to the ON position.
Essential Safety Equipment
Seat Belt Systems
2-30
*Some models.
