Compass Display
The direction the vehicle is moving is
displayed in one of eight directions
while the vehicle is being driven.
Display Direction
N North
SSouth
EEast
WWest
NE Northeast
NW Northwest
SE Southeast
SW Southwest
▼
Message Display
A message such as the system
operation status, a malfunction, or an
abnormality is indicated.
Warning/indicator light in instrument
cluster turns on/flashes or symbol is
indicated on display at same time as
message
Check the information regarding the
warning/indicator light or indicated
symbol.
Refer to If a Warning Indication/
Warning Lights on page 4-19.
Refer to If a Indication/Indicator Lights
on page 4-21.
Message only is indicated on display
Follow the instructions indicated on
the display. For the display content,
refer to the next page.
Refer to If a Message Indicated on
Multi-information Display on page
7-33.
▼
Warning/Indicator Lights
Instrument Cluster varies depending
on model and specifications.
1. Instrument Cluster
2. Front Center of Headliner
Warning lights will appear in any of the
highlighted areas
When Driving
Instrument Cluster and Display
4-18
