Display range
1. Target object
Viewing the screen
Display/Icon Content
(1) Projected vehicle path lines (yellow) Indicates the approximate projected path of the vehicle.
Moves in conjunction with the steering wheel operation.
The projected vehicle path lines (yellow) indicate the
path the inner side of the vehicle is expected to travel.
(2) Vehicle parallel guide lines (blue) Indicates the approximate vehicle width including the
door mirrors.
When Driving
i-ACTIVSENSE
4-160
