Rear camera
1. (Screen display)
2. (Actual condition)
3. Sensed distance on screen A>B>C
4. Actual distance B>C=A
▼
System Problem Indication
Center display indication Cause Action to be taken
“No camera signal.” is displayed The control unit might be damaged. Have your vehicle inspected
by an Authorized Mazda
Dealer.
Screen is pitch-black and blank The camera might be damaged.
When Driving
i-ACTIVSENSE
4-175
MX30_8JD4-EA21G_Edition4_new 2021-8-5 15:25:29
