The system may have a malfunction if a message indicating a system malfunction is
displayed. Have your vehicle inspected by an Authorized Mazda Dealer.

A message may be displayed even when the ambient temperature is extremely
cold, or mud, ice, or snow adheres to the sensor area. Remove any foreign matter
from the sensor area.
▼
Sensor Detection Range
The sensors detect obstructions within the following range.
1. Front ultrasonic sensor detection range
2. Rear corner/Rear side ultrasonic sensor detection range
3. Rear ultrasonic sensor detection range
4. Front corner ultrasonic sensor detection range
A About 55.0 cm (About 21.6 in)
B
About 150 cm (About 59.0 in)
C About 100 cm (About 39.3 in)
Viewing distance display
Display
Distance between vehicle and obstruc-
tion
Without 360° view monitor
With 360° view
monitor
Front ultrasonic
sensor
*
/Front cor-
ner ultrasonic sen-
sor
*
Rear ultrasonic sen-
sor/Rear corner ul-
trasonic sensor/
Rear side ultrasonic
sensor
*
Without front ul-
trasonic sensor
and front corner
ultrasonic sensor
With front ultra-
sonic sensor and
front corner ultra-
sonic sensor
Green
Front ultrasonic sen-
sor:
Approx. 100―60.0
cm (39.3―23.6 in)
Rear ultrasonic sen-
sor:
Approx. 150―60.0
cm (59.0―23.6 in)
When Driving
Parking Sensor System
4-200
*Some models.
