No.
FUSE RAT
ING
PROTECTED COMPONENT
F8 10 A Motor control system
F9 15 A Charge control system
F10 10 A BEV control system
F11 7.5 A Air conditioner
F12 10 A BEV control system
F13 ――
F14 ――
F15 20 A ―
F16 15 A For protection of various circuits
F17 15 A Water pump
F18 15 A Accessory sockets
F19 60 A Power steering system
F20 15 A Headlight (LH) 1
F21 15 A Headlight (RH) 1
F22 15 A Keyless system
F23 30 A ABS, Dynamic stability control system
F24 15 A Headlight (LH) 2
F25 15 A Headlight (RH) 2
F26 7.5 A On board diagnostics
F27 25 A For protection of various circuits
F28 25 A For protection of various circuits
F29 15 A Windshield washer
F30 ――
F31 15 A Horn
F32 ――
F33 ――
F34 20 A BEV control system
F35 50 A ABS, Dynamic stability control system
F36 30 A Parking lock
F37 30 A Rear window defogger
F38 50 A For protection of various circuits
F39 ――
F40 40 A Air conditioner
Maintenance and Care
Owner Maintenance
6-30
