Specifications
▼
Charge System
Item Servicing data
Input power 110 - 240 V AC (single phase)
Rated frequency 60 Hz
Maximum rated electrical current 32 A (normal charge)
Maximum power consumption 7.68 kVA (normal charge)
Maximum charging current 100 A (quick charge)
Electrical leakage detection current
for control box including genuine
charge cable
5 mA
EV charge mode/Connection type
Normal charge: AC Level 1, AC level 2
Quick charge: CCS1 (Combo1)
Installation requirements
(information on protection against
short-circuit current and equipment
protection)
Applicable laws and regulations, and standards must be followed
for protection measures against over-current and over-voltage.
Always make sure to install appropriate over-current protection
devices to the wiring of houses and buildings.
IP level
IP44: When charge connector is connected to charge inlet
IP67: Charge cable
Operating temperature
Onboard charger: -30 °C (-22 °F) ― 65 °C (149 °F) (coolant
temperature). Performance degrades at 60 °C (140 °F) or higher
Charge cable: -30 °C (-22 °F) ― 50 °C (122 °F) (ambient tem-
perature)
Storage temperature
Onboard charger: -40 °C (-40 °F) ― 65 °C (149 °F) (coolant
temperature), -40 °C (-40 °F) ― 85 °C (185 °F) (ambient tem-
perature)
Charge cable: Vehicle guaranteed temperature
Applicable standards
Onboard charger: EN/IEC 61851-1, EN/IEC 61851-21,
EN/IEC 61851-23, UL 2202
Charge cable: NFPA 70, NFPA 79, SAEJ 1772, UL 62, UL 817, UL
2231-1, UL 2231-2, UL 2251, UL 2594, CSA C22.2 No.280-16
Adapters
Do not use an adapter on the charge plug and the charge con-
nector.
Do not use an extension cable.
▼
High Voltage Battery
Item Specification
Type Lithium-ion battery
Specifications
Specifications
9-3
