Engine Compartment Overview
Engine oil dipstick
Engine oil filler cap
Brake fluid reservoir / Clutch
fluid reservoir (only for manual
transmission model)
Washer fluid reservoir
Cooling system cap
Battery
Engine coolant reservoir
Power steering fluid cap
Air filter Fuse block
8-14
Maintenance and Care
Owner Maintenance
