qFront Air Bag System Components
(4)
(8)
(7)
(5)
(2)
(9)
(3)
(1)
(6)
(5)
(1) Front dual stage inflators and air bags
(2) Front crash sensor
(3) Passenger air bag deacti vation indica tor light (page 2-37)
(4) Crash sensor and diagnostic module (SAS unit)
(5) Seat belt pretensioner and load limiting systems (page 2-10)
(6) Passenger seat weight sensors (page 2-37)
(7) Driver and passenger seat belt buckle switches (page 2-37)
(8) Driver seat slide position sensor (page 2-37)
(9) Seats
