Refer to Closing the Roof on page
3-44.
Multi-information
display indication
11. Switch the ignition OFF.
12. Remove the windblocker.
Windblocker
13. Partially peel back the cover on the
right side from the middle of the
vehicle.
14. Pull out the cap and release the trunk
lock.
After performing this emergency
measure, have the vehicle inspected at
an Authorized Mazda Dealer as soon
as possible.
CAUTION
Do not pull the screw when pulling the cap.
Otherwise, the screw may fall o and
become lost.
Roof does not operate electrically
1. Remove the antenna if it is installed.
Refer to Antenna on page 5-17.
2. Lift up the rear roof by hand.
Refer to When the Roof Cannot be
Closed on page 7-57.
If Trouble Arises
When Trunk Lid Cannot be Opened
7-55
