6
–
45
Maintenance and Care
Owner Maintenance
*Some models.
4. Pull the centre of each plastic retainer
and remove the retainers, and then
partially peel back the boot side trim.
Removal
Installation
5. Remove the screw and nut.
6. Pull the unit rearward to remove it.
7. Turn the socket and bulb assembly
anticlockwise and remove it.
8. Disconnect the bulb from the socket.
9. Install the new bulb in the reverse order
of the removal procedure.
Reverse lights, Rear fog light
*
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Turn the socket and bulb assembly
anticlockwise and remove it.
3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverse order
of the removal procedure.
