Maintenance and Care
Owner Maintenance
*Some models.
DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
18 A/C MAG 7.5 A Air conditioner
19 AT PUMP 20 A Transmission control system
*
20 AT 15 A Transmission control system
*
21 D LOCK 25 A Power door locks
22 H/L RH 20 A Headlight (RH)
23
ENG
B2
7.5 A Engine control system
24 TAIL 20 A Tail lights, Number plate lights, Position lights
25 DRL 15 A —
26 ROOM 25 A Overhead light
27 FOG 15 A —
28 H/CLEAN 20 A Headlight washer
*
29 STOP 10 A Brake lights, Rear fog light
*
30 HORN 15 A Horn
31 H/L LH 20 A Headlight (LH)
32 ABS/DSC S 30 A ABS, Dynamic stability control system
33 HAZARD 15 A Hazard warning fl ashers, Direction indicator lights
34 FUEL PUMP 15 A Fuel system
35
ENG
B3
5 A —
36 WIPER 20 A Windscreen wipers
37
CABIN
B
50 A For protection of various circuits
38 — — —
39 — — —
40 ABS/DSC M 50 A ABS, Dynamic stability control system
41
EVVT
A/R PUMP
20 A Engine control system
42 EVPS 30 A Brake control system
43 FAN1 30 A Cooling fan
44 FAN2 40 A —
45 ENG.MAIN 40 A Engine control system
46 EPS 60 A Power steering system
47 DEFOG 30 A Rear window defogger
48 IG2 30 A For protection of various circuits
49 INJECTOR 30 A Engine control system
50 HEATER 40 A Air conditioner
51 — — —
52 — — —
