CONSOLE DISASSEMBLY/ASSEMBLY
Front Console
1. Disassemble in the order indicated in the table.
1 Front console
2 Side wall
2. Assemble in the reverse order of disassembly.
Rear Console
1. Disassemble in the order indicated in the table.
1 Rear console
2 Glove compartment lid
3 Console panel
4 Front console box
5 Rear console box
6 Console cover
7 Outer console lid
2. Assemble in the reverse order of disassembly.
