Mazda TRIBUTE 2008 - Climate Controls

CLIMATE CONTROLS
Always check the Owner’s Manual for more operating information and safety features
Climate
Controls
Climate
Controls
*Denotes optional equipment
1. Fan speed
Rotate knob to control
air volume.
2. Air flow selections
= air to dash
= air to dash and floor
= air to floor
= air to floor and
windshield
= defrost, air to
windshield
3. Power
Press to activate/deactivate
climate control system.
4. Temperature selection
Cooler/warmer = rotate knob
counterclockwise/clockwise
5. Heated seats*
Press ON/OFF.
6. Recirculated air
Press to activate/deactivate.
WARNING: Do not use
r
ecirculated air mode in
cold weather, windows
may fog and hamper
vision.
7. MAX A/C
Distributes cooled recirculated
air through instrument panel
vents for maximum cooling.
8. A/C
Air conditioning ON/OFF.
9. Rear defrost
Press to activate/deactivate.
Tip: Both outside mirrors
ar
e heated* automatically
to help remove ice, mist
and fog when rear window
defrost is activated.
Control positions for
maximum defr
ost
Press button; fan to maximum,
temperature to maximum hot.
Tips: To help prevent windshield
fogging in humid weather,
select before starting engine.
To prevent moisture buildup,
never drive with system off.
Objects placed under the front
seats may interfere with air
flow to the rear.
1
2
3
4
A/C
R
MAX A/C
1 3 42 2
5 8 7 6 59
