Mazda Tribute - Gauges

GAUGES
Shown in standard measure. Metric similar.
Speedometer: Indicates the
current vehicle speed.
Engine coolant temperature
gauge: Indicates engine coolant
temperature. At normal operating
temperature, the needle will be in
the normal range (between “H” and
“C”). If it enters the red section,
the engine is overheating. Stop
the vehicle as soon as safely
possible, switch off the engine and let the engine cool.
60
100
x1000/min
4
0
1
2
3
5
6
7
8
km/h
0
0
20
40
60
80
120
140
160
180
200
20
40
80
100
120
mph
E
F
C
H
Instrument Cluster
17
2011 Tribute (j14)
Owners Guide, 1st Printing
USA (fus)
