6 First time operation
Connect,dependingondevicetype,anantenna,andinsertaSIMcard.
BeforeconnectingtheroutertoanetworkorPC,rstensurethatitisproperlyconnected
toapowersupply,otherwiseitmaycausedamagetootherequipment.
•Connectequipotentialbondingtothegroundinglugontherouter’stoppanel.
•Connectthe(10-30VDC)powersupplytotheX1terminaloftherouter.
Achten Sie auf die richtige Polung!
◦ AfterswitchingonthesupplyvoltagethePwrLEDlightsupandthedeviceperforms
asystemcheck.
◦ Afterabout25sec.,bothLEDPwrandLEDErrlightup.
◦ Afteranother25sec.,LEDErrturnso󰀨andtheLEDRdyashes.
◦ Afteratotalofabout90sec.,bothLEDPwrandLEDRdylightup.
ThembNETisnowreadyforoperation.
