MB QUART MAXX-LINK MLX-100 - Bridging Module

MAXX-LINK MLX-100 BRIDGING MODULE
LEVEL
BYPASS
NORMAL
RED - CLIP
GREEN - 9V
-20dB 0dB
-6dB
INPUT
LEVEL
PHASE BOOST
PARAMETRIC BASS EQ
BANDWIDTH FREQUENCY
0.2V 180 +10 dB 100Hz9V 0 0dB 30Hz
MAXX-LINK
MLX-100
SUBSONIC
FILTER
24 dB/OCT
LOW PASS
FILTER
24 dB/OCT
OUTPUT
LEVEL
MODE
ON
SLAVE
OFF
MASTER
RED - CLIP
GREEN - 9V
TEST TONE
65Hz
35Hz250Hz 1V 9V
5V
7V3V
15Hz35Hz
BR-1 Remote Module
NORMAL OPERATION: Allows use of variable
LEVEL control.
BYPASS OPERATION: Ouput is fixed at 0dB.
By switching between NORMAL and BYPASS
operation, you can create BURSTS of high to
low audio output.ie: Burping
INPUT
INPUT
LEFT
RIGHT
FULL RANGE
BR-1 REMOTE
CONTROL
MASTER OUT
SLAVE IN
BRIDGING OUTPUTS
A B C D E
+ + + + +
- - - - -
GND REM
+12V
REMOTE TURN-ON
CHASSIS GROUND
TO BATTERY + 12v VIA 1amp FUSE
2
