Fig. 2
TECHNICAL DATA
Technical characteristics
Product name THERMO VULKAN
Product purpose Solid fuel stove for central heating
Nominal power (wood/ coal) 19,7 / 24.8 kW
Power given to water (wood/ coal) 14 / 14.5 kW
Power given to room (wood/ coal) 5,7 / 10,3 kW
Efficiency
- wood 86%
- coal 85%
Dimensions of stove (HxWxD) 780 x 650 x 500 mm
Dimensions of firebox (HxWxD) 310 x 400 x 400 mm
Weight (wihtout water/ with water) 156 / 177 kg
Minimal distance from combustible
materials
- back 50 cm
- side 50 cm
- front 80 cm
Emission of CO (reduced to 13% O2)
- wood 0,07 % 0,966 g/m³
- coal 0,08 % 1,003 g/m³
Emission of dust
- wood 0,037 g/m³
- coal 0,039 g/m³
Chimney connection Ø120 mm
Position of chimney connection central top
Average temperature of smoke gases
(wood/ coal) 227,5 / 199 °C
Air regulation primary, secondary
Draft 10-14 Pa
Amount of water in boiler 24 l
Water connection diameter 1"
Max. temerature of the water in boiler 90 °C
Max. working pressure 2 bar
