30
PHONO PHONO
SOUND SYSTEM
TAPE
CD
Connection
Connection example:
Initial operation
Do not turn the CD tuner on before you have read and understood these operating instructions.
Check again that all connections are correct.
a) Switching the mixing desk on/off
Not observing the the following sequence when switching the mixer on and off could damage
the loudspeakers or the amplifier.
Switching on
• Make sure that all channel faders (7) are set to minimum volume (channel fader pulled right back to the lowest
point).
• Switch on the output devices that are connected to the mixer first.
• First, switch on the mixing desk via the on/off switch (12).
• Switch the connected amplifier on. The mixing desk is now ready for operation.
