Power requirements
The E45 can be supplied for nominal mains voltage of 115V or 230V.
An internal link can be set to either 100V or 120V for the 115V version and 220V or 240V for the 230V
version. Normally these are set to 120V and 240V respectively.
This amplifier will only operate to its very high specification if it is installed and operated
as described in this manual.
APPENDIX
Table of PRC settings and average relative output
-
--
-
E45
E45E45
E45
Output Per Channel (Watts) Bridged Mode (Watts)
Max Power into 4ohm 2250 6400
-2dBu PRC Setting 1400 4000
-4dBu PRC Setting 900 2500
-6dBu PRC Setting 560 1600
Max Power into 8ohm 1200 4400
-2dBu PRC Setting 800 2800
-4dBu PRC Setting 525 1800
-6dBu PRC Setting 350 1200
Max Power into 2ohm 3200 N/A
-2dBu PRC Setting 2000 N/A
-4dBu PRC Setting 1250 N/A
-6dBu PRC Setting 800 N/A
