McAfee NS9100 - Slide Rail Installation - Rack and Chassis; Install Slides to Rack; Install Inner Member to Chassis

2
Rack installation - Install slides to rack
Align brackets to desired vertical position on the rack and insert the fasteners. Move the ball retainer to the
front of slides.
Do not handle the NS-series appliance by the mounting brackets
3
Chassis installation - Install inner member to chassis
Align inner member key holes to standos on chassis, move inner member following the direction the
picture.
