2.9.8 Alarm Descriptions
FAILURE DESCRIPTION
HA Pressure switch failure
F1 Internal temperature sensor failure
F2 External temperature sensor failure
bL Battery lower 10 VDC failure
AL Alternator failure
LC 3 Pressure switch failures (HA) in 30 min.
Pd Discharge pressure failure
Ps Suction pressure failure
Figure 2-9 EnviroMATE Alarms (Single Zone)
